Huawei Enterprise Router AR6280-S
Rp119.014.200
Deskripsi
| Item | Specification |
|---|---|
| Installation type | Rack |
| Dimensions without packaging (H x W x D) [mm(in.)] |
|
| Dimensions with packaging (H x W x D) [mm(in.)] | 185 mm x 740 mm x 585 mm (7.28 in. x 29.13 in. x 23.03 in.) |
| Chassis height [U] | 2 U |
| Weight with packaging [kg(lb)] | 13.5 kg (29.7 lb) |
| Weight without packaging [kg(lb)] | 10.35 kg (22.77 lb) |
| Power supply mode | AC external |
| Number of power modules | 2 |
| Rated input voltage [V] |
|
| Input voltage range [V] |
|
| Maximum input current [A] | 5 A |
| Maximum output power [W] | 350 W |
| Type of fans | Pluggable |
| Number of fan modules | 1 |
| Heat dissipation mode | Air cooling |
| Airflow direction | Left to right |
| Extended slots (standard configuration) |
|
| Number of service board slots | 8 |
| Redundant power supply |
|
| RPS input | Not supported |
| Noise at normal temperature (acoustic power) [dB(A)] | 54.2 dB(A) |
| Long-term operating temperature [°C(°F)] |
0°C to 45°C (32°F to 113°F) NOTE:
When the altitude is 1800 m-5000 m (5906 ft.-16404.2 ft.), the highest operating temperature reduces by 1°C (1.8°F) every time the altitude increases by 220 m (722 ft.). |
| Storage temperature [°C(°F)] | -40°C to +70°C (-40°F to +158°F) |
| Long-term operating relative humidity [RH] | 5% to 95%, noncondensing |
| Long-term operating altitude [m(ft.)] | < 5000 m (16404.2 ft.) |
| MTBF [year] | 27.55 year |
| MTTR [hour] | 2 hour |
| Availability | 0.9999929422 |
