USG6360-BDL-AC Specification

USG6360-BDL-AC Specification
Dimensions (H x W x D)	44.4 mm x 442 mm x 421 mm
Form Factor/Height	1U
Fixed Interfaces	4 x GE (RJ45) + 2 x GE (Combo)
USB 2.0 Port	Supported
Expansion Slot	2WSIC^*
Expansion I/O	WSIC: 2 x 10 GE (SFP+) + 8 x GE (RJ45), 8 x GE (RJ45), 8 x GE (SFP), and 4 x GE (RJ45) BYPASS
Maximum Number of Interfaces	22 x GE (RJ45) + 4 x 10 GE (SFP+) or 18 x GE (SFP) + 4 x GE (RJ45)
MTBF	11.58 years
Weight (full configuration)	7.9 kg
Local Storage	Optional. Supports a 300 GB or 600 GB hard disk (the hard disk is hot-swappable, but the hard disk card is not)
AC Power Supply	100V to 240V, 50 Hz/60 Hz
Power Consumption (average/maximum)	30.7W/107.83W
Heat Dissipation	368 BTU/h
Power Supplies	Single 150W AC power supply; optional 170W AC power supply
Operating Environment (temperature/humidity)	Temperature: 0°C to 45°C (without optional HDD) 5°C to 40°C (with optional HDD) Humidity: 5% to 95% (without optional HDD), non-condensing 5% to 90% (with optional HDD), non-condensing
Non-operating Environment	Temperature: -40°C to 70°C Humidity: 5% to 95% (without optional HDD), non-condensing; 5% to 90% (with optional HDD), non-condensing
Operating Altitude (maximum)	5,000 meters (without optional HDD); 3,000 meters (with optional HDD)
Non-operating Altitude (maximum)	5,000 meters (without optional HDD); 3,000 meters (with optional HDD)
Noise	54.1 dBA

USG6360 AC Host
